110122T01 Superior Essex Loose Tube Single Jacket All Dielectric
MFR #:85-147-01
GCG #:85-147-01
MFR #:85-147-01
GCG #:85-147-01
Min Qty:1
  | ÂQty Increment:1
Loose tube cables are the product of choice as the backbone in Outside Plant (OSP) applications. Loose tube self support cables are designed for use in aerial applications as an alternative to lashing. These cables reduce installation time and costs. Superior Essex offers self support cables for spans up to 700 feet. The loose tube design offers reliable transmission performance over a broad temperature range. The rugged loose tube design features optical fibers placed inside PFM gel-filled buffer tubes. The core is constructed by stranding the buffer tubes around a central member using a reverse oscillating lay (ROL). The core is wrapped with flexible strength members, a water-blocking tape and then encased with a black jacket and an integrated EHS steel messenger. A rip cord is included under the jacket for ease of entry.
Request Quote
Min Qty:1
  | ÂQty Increment:1
Loose tube cables are the product of choice as the backbone in Outside Plant (OSP) applications. Loose tube self support cables are designed for use in aerial applications as an alternative to lashing. These cables reduce installation time and costs. Superior Essex offers self support cables for spans up to 700 feet. The loose tube design offers reliable transmission performance over a broad temperature range. The rugged loose tube design features optical fibers placed inside PFM gel-filled buffer tubes. The core is constructed by stranding the buffer tubes around a central member using a reverse oscillating lay (ROL). The core is wrapped with flexible strength members, a water-blocking tape and then encased with a black jacket and an integrated EHS steel messenger. A rip cord is included under the jacket for ease of entry.
- Attributes
Attributes
General Information
BrandALPETH
ManufacturerSuperior Essex
PackagingReel
Product CategoryPremises Fiber
Design & Construction
ColorBlack
MaterialPE
EnvironmentOutdoor
Gauge Size26 AWG
Water BlockGel
Electrical Properties
Insulation MaterialPolyolefin
